Omnidirectional QR Scanner Engine IP54 Waterproof For Mobile Payments Scanning Plan

Brand Name:	SR
MOQ:	10pcs
Price:	2usd
Payment Terms:	L/C, T/T
Supply Ability:	10,000 pcs/day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Rohs，Aiming (red laser) :EN/IEC 60825-1:2007 (class 2)

Product:

QR Code Engine

Communication Interface:

USB HID，USB VCOM，RS232，Ethernet

Operating Temperature:

-20℃ To 50℃[-22℉ To 140℉]

Storage Temperature:

-40℃ To 70℃[-40℉ To 158℉]

Lighting Environment:

0~100000ux

Operating Voltage:

DC5V±10% (USB), DC5V-24V (232/external Power Supply)

Working Current:

500mA（Max）@5V

Packaging Details:

Carton

Highlight:

Omnidirectional QR Code Engine

ip54 QR Code Engine

waterproof qr engine

Product Description

Efficient QR Scanner Engine for Mobile Payments Scanning Plan

Description:

The efficient QR scanner engine for mobile payments scanning plan is a high-performance electronic component designed specifically for mobile payment scanning. It possesses the ability to process QR code information quickly and accurately.

The efficient QR scanner engine for mobile payments scanning plan has several features. Firstly, it utilizes high-speed image processing algorithms, enabling fast capture and decoding of QR codes, providing real-time scanning feedback. Secondly, it supports a wide range of QR code types, including payment codes, merchant information, and transaction details, catering to various mobile payment needs. Thirdly, it has an optimized user interface and user experience, simplifying the scanning process and reducing user complexity. Fourthly, it typically has stable connectivity capabilities, such as Bluetooth or NFC, facilitating seamless integration with mobile devices.

The efficient QR scanner engine for mobile payments scanning plan is widely used in the field of mobile payments. Whether it's shopping in stores, dining out, or making online payments, users can quickly and conveniently complete the payment process using this engine. It enhances the efficiency and convenience of mobile payments, providing a better payment experience for both merchants and consumers.

Specification:

Image Senor	Global shutter
Resolution	*12801080**
Illumination	Red LED
Aim	Laser
Field of View	H:40.9°；V:31.2°
Reading Angle	Tilt: ±70° rotation 360° deflection ±55°
Readable Contrast	15%
Support Code System
1D	Codabar,Code11,Code128,ISBT128,Code32,Code39,TLC39,Code93/93i, BC412,UK Plesey,Anker Plesey,EAN-13,EAN-8,GS1,MSI,Telepen, Pharma,PatchCode,UPC-A,UPC-E,2 fo 5 (ChinaPost,Interleaved 2 of 5,Matrix 2 of 5,NEC 2 of 5,Straight 2 of 5 iATA,Straight 2 of 5 Industrial)
2D	AztecCode,HanXin,DataMatrix,MaxiCode,QR,Micro QR,rMQR, Dot Code,GridMatrix,CodablockA,CodablockF,PDF417,Micro PDF417
Postal	KoreaPost,ChinaPost,AustraliaPostal,Royal INFOMAIL,Japan Postal,KIX,PLANETCODE,POSTNET,BritainPostal,UPU,USPS 4STATE
Depth of Field(100MM)
Coding System	Effective Reading Distance (mm)	Depth of Field (mm)
5mil code39	60-150	90
13mil EAN13	50-325	275
10mil DM	40-225	185
15mil DM	35-295	260
20mil Code	135-415	280

Details:
