Handheld Cold Chain PDA Barcode Scanner Low Temperature Durable
Description:
The handheld cold chain PDA barcode scanner is specifically designed for use in cold chain logistics and temperature-controlled environments. It is built to withstand low temperatures and harsh conditions commonly found in cold storage facilities, refrigerated trucks, and other cold chain settings.
Equipped with a rugged and durable casing, this scanner offers robust protection against extreme temperatures to ensure reliable performance. It is designed to operate flawlessly in freezing conditions, allowing users to scan barcodes accurately and efficiently, even in sub-zero environments.
Specification:
| Specifications | |
| OS | Android 12 |
| CPU | Octa Core CPU, 12nm |
| MEMORY | 3+32 |
| Extend Slot | MicroSD, support SDHC, up to 128GB; |
| Nano | |
| PC Communication | USB 2.0 OTG : Type-C； |
| Sensers | Gravity sensor, proximity detector, Photosensitive sensor, Hall element, temperature and humidity sensor, status lamp |
| LED | Charging, Scan and System stauts |
| Charging Time | ≤2.5 h (Room Temperature) |
| Operation Duration | 18 hours |
| Data Collection | |
| Scan Engine | Support VGA Dual Camera scan engine |
| 2D | Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code |
| Micro QR Code; QR Code; EAN/JAN Composites; GS1 DataBar Composites; | |
| GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; | |
| GS1 DataBar Stacked Omnidirectional; MacroPDF; | |
| MicroPDF417; PDF417; UPC A/E Composites;Digimarc(E3250 supports) | |
| 1D | Auto discriminates all standard 1D codes including GS1,code39,code 128,code93 |
| DataBar™ linear codes. | |
| Post | Australian Post; British Post; China Post; IMB; Japanese |
| Post; KIX Post; Korea Post; Planet Code; Postnet; Royal | |
| Mail Code (RM4SCC) | |
| NFC(Optional) | 13.56MHz NFC |
| Wireless Connectivity | |
| WLAN | 802.11 a/b/g/n/ac, 5G FEM PA |
| WWAN | WWAN ROW GSM: QB UMTS: B1/B2/B5/B8 FDD_LTE:B1/2/3/5/7/8/20/28 TDD_LTE:B34/B38/39/40/41 |
| WWAN NA GSM: QB UMTS: B1/B2/B5/B8 FDD_LTE:B2/B4/B5/B7/B12/B17/B25/B26 |
|
| VoLTE | LTE CAT6 |
| CA | Downlink 300Mbps, B1/B3/B39/B40/B41 |
| WPAN | BT 5.1 |
| GPS | GPS/Glonass/Beidou,Assisted GPS |
| Physical Specifications | |
| LCD | 4” , IPS, 800*480, 450nits |
| Touch | Capacitive screen, High strength glass |
| Camera | Auto focus 13Mega, dual flash LED |
| Keypad | Left/Right Scan Key, Vol+/Vol- Key, Power Key,K1/K2 Function Key |
| Reciver | Support |
| Speaker | Double speaker, Greater than 100db |
| Mic | Double Mic with Noise Reduction |
| Charging IO | USB type-C |
| Battery | Removable 4450mAh, Special cell for cold chain, Built-in small battery80mA, 8C |
| Dimension | 166*71*17mm(Without Scan Window) |
| Weight | 274g(With battery) |
| Environmental Specifications | |
| Operation Temperature | -30°C to 55°C |
| Storage Temperature | -30°C to 70°C |
| Humidity | 5%-95% non-condensing |
| Drop | 1.8m on concrete, 3 times on each side |
| Tumble | 3000 hits of 0.5m tumble, 600 hits of 1m tumble |
| IP | IP67 |
| ESD | ± 8 kV contact discharge, ± 15 kV air discharge, |
| Keypad lifecycle | 100k |
